WERNER 7114-1 7100-1 Type IAA Duty Single Section Straight Ladder, 14 ft H x 18-1/16 in W, 375 lb Load, 14 ft Top Step, Fiberglass
WERNER 7114-1 14' FIBERGLASS SINGLE LADDER (YELLOW) TYPE IA 375#
Straight Ladders
}
WERNER 7114-1 7100-1 Type IAA Duty Single Section Straight Ladder, 14 ft H x 18-1/16 in W, 375 lb Load, 14 ft Top Step, Fiberglass
2500429
MFG #: 7114-1
Product ID:2500429
Famous Supply
- Number of Rungs: 14
- Rung Diameter: 1-1/4 in
- Rung Spacing: 12 in
- Rung Type: Round
- Rung Width: 1-1/4 in
- Series: 7100-1
- Top to Bottom Rung: 13 ft
- Tread: Slip-Resistant
- Type: Type IAA Duty Single Section
- Overall Height: 14 ft
- Overall Width: 18-1/16 in
- Load Capacity: 375 lb
- Material: Fiberglass
- Top Step Height: 14 ft
The 7114-1 one section round rung 14 ft straight ladder is made with non-conductive fiberglass rails. Easy to transport and maneuver, these ladders bear a duty rating of 375 lb making them durable and long lasting. The slip resistant, TRACTION-TRED® rungs are round, and the durable rail shields and shoe brackets help to protect the rails from damage. The plate and rung assemblies are riveted at four points to the side rails.
- Features
- Standards & Approvals
- Application
| Exclusive ALFLO® rung joint means TWIST-PROOF® performance |
| 1-1/4 in slip resistant TRACTION-TRED® round rungs |
| Plate and rung assembly are riveted at four points to each side rail to allow for rung replacement |
| Rugged, heavy duty extruded rung locks are spring loaded to operate smoothly |
| Pre-pierced holes for easy field installation of accessories |
| Durable rail shield and shoe bracket protects rail from damage |
| Dual action feet with slip resistant pad and spur plate for use on hard or penetrable surfaces |
| Mar resistant molded end caps |
| Ideal for utility and telecommunication industries |
| Shoe with slip resistant pad and spur plate |
| 1 section |
| 17 ft H reach |
| 14 ft L open extended |
| 14 ft L closed |
| 3-5/16 in rails |
| 1-3/16 in flange |
| 16-13/16 in W fly |
| ANSI A14.5 (2007), OSHA Approved |
| Climbing Equipment |
